Products – Ozone Generator L Series – framelife

Faraday Ozone’s

Excellent performance
L Series Ozone Generator

Experience unrivaled ozone generation excellence, elevating your applications with superior efficiency and reliability.

Request for quote

Micro Processor based Technology are used

Micro Processor based Technology

Micrprocessor based operaiton to perform functions of oxygen concentrator that accepts digital signals as the input source and processes.

High Efficiency Compressor

We use oil-free air compressors to achieve highest air purity standards. It is less expensive, light weight, faster start, less noise.

Robust Ozone Electrodes

Pressure sensor is used to detect inhalation, which then controls the regulator. It detect the low flow rate of breathing.

Lowest Power Consumption

There are 3 air filtres – Primary air filter, Hepa filter and Bacterial filter. To produce oxygen, concentrator draws in ambient air through filtration process.

Ozone generator l series front view

High ozone concentration up to 6 to 12 wt%

High Voltage & High Frequency Corona Discharge

Robust Ozone Electrodes

Display shows oxygen purity, flow and cumulative hours of operation in digital format for easy understanding

Lowest power consumption

Consumes very less electricity and produces less heat compared to other brands in the market

Linear Ozone Control

Easy access panel allow you to monitor and control the performance with LED indication, ozone output adjustment, air flow meter and switch

Reliable Ozone Production

Maximum ozone production reliability is achieved, long life special steel electrodes and provides high concentration ozone with dry air

Effective Fans

Highly effective fans to remove heat and make the machine cool for better heat dissipation and improves overall machine efficiency and life

Optional 4-20 mA signal

4-20 mA analog interface option to connect the ozone generator to the PLC or external controller to control the ozone generator

Technical Specifications

Model	L10G	L20G	L30G	L40G	L50G	L60G	L100G	L200G	L300G
Input Power	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz	230 V AC 50 Hz
Power Consumption	90 Watts	90 Watts	150 Watts	230 Watts	250 Watts	280 Watts	800 Watts	1800 Watts	2600 Watts
Ozone Capacity	10 gm/hr	20 gm/hr	30 gm/hr	40 gm/hr	50 gm/hr	60 gm/hr	100 gm/hr	200 gm/hr	300 gm/hr
Ozone Concentration	6 – 8 % W	6 – 8 % W	6 – 8 % W	6 – 8 % W	6 – 8 % W	6 – 8 % W	8 – 12 % W	8 – 12 % W	8 – 12 % W
Feed gas	3 to 5 lpm	3 to 5 lpm	3 to 5 lpm	3 to 5 lpm	3 to 5 lpm	3 to 5 lpm	10 to 15 lpm	20 to 30 lpm	20 to 30 lpm
Dimension (LxWXH)	270 x 210 x 420 mm	270 x 210 x 420 mm	370 x 210 x 420 mm	420 x 210 x 600 mm	420 x 210 x 600 mm	420 x 210 x 600 mm	457 x 490 x 1034 mm	550 x 969 x 1350 mm	550 x 969 x 1350 mm
Weight	10kg	10kg	15kg	17kg	18kg	18kg	55 kg	140 kg	150 kg

Frequently Asked Questions

What is Ozone?

Ozone, (O3), sometimes called “activated oxygen”, contains three atoms of oxygen rather than the two atoms we normally breathe. Ozone is the second most powerful Purifier in the world and can be used to destroy bacteria, viruses and odors.

Why should i buy faraday’s ozone generator more than others?

Faraday’s ozone generator contains patented innovative ozone techniques to produce ozone, which is air-cooled and results in low cost, minimal maintenance, lowest power consumption, easy installations and many. We have 20+ patented ozone products and we are ISO certified too. We export more than 50+ countries with proper sales and service support as well.

What is corona discharge ozone generator?

High voltage electric supply applied into the ozone generator provides the energy required to form electrical arcs known as corona discharge inside the patented corona cells. These corona discharge splits the oxygen molecules into oxygen atoms which recombine to form ozone.

How does ozone generator works?

The ozone generator is an electronic system which converts oxygen into ozone using the principle of corona discharge technology. High voltage electric supply applied into the ozone generator provides the energy required to form electrical arcs known as corona discharge inside the patented corona cells. These corona discharge splits the oxygen molecules into oxygen atoms which recombine to form Ozone. The produced ozone is then used for water and air treatment.

What is the half life of ozone?

Ozone disappears rapidly and it is produced by ozone generator at the site for water and air treatment of various applications. Because of its short life, ozone reacts and decomposes soon when produced. The half life of ozone in the water is about 30 minutes, which means that every half hour the ozone concentration will be reduced to half its initial concentration.

What is the warranty period of ozone generator?

Warranty of ozone generator is 1 year.

Our Esteemed Customers

Patented Ozone technology

Our ozone cells are patented and comes with for long life special steel produces mass ozone

Low Power Consumption

Consumes very less electricity and produces less heat compared to other brands in the market

Easy to Operate

Accessing front panel allows you to monitor and control the operation of the entire system

4-20 mA signal

Option to connect the ozone generator to the PLC or external controller to control the system

Service and Installation
ACROSS INDIA

We are here to do service and installation support after sales. We have a team of engineers available round clock to handle and to provide
prompt solution for your service related queries effective and supportive towards product installation.

5000+

Installations

25+

Dealers

20+

Trained Service Engineers

50000+

Product Installations

Extended Warranty Upto 2 Year

Our Ozone Generator are robust and reliable which offer a no-hassle 2 year warranty. We are confident enough on our technology and warranty covers for core materials like ozone electrodes and PCB comes for longevity. We recommend you to clean the fans filters and entire machine at least once in a month and replace the ozone power board and electrodes on a timely basis.

2 year warrenty for the product

Product Certifications

got iso certification

got more patent certification

got dsir recognized certification

member of eu certification

Global Footprint in 50+ Countries
